20" Big Blue Sediment Water Filter | 10 Micron Filtration Rating | Melt-Blown Polypropylene Depth Filter

10 Micron Sediment Filter for 20" Big Blue Housing
Removes Dirt, Rust, Sand, Silt, and Other Suspended Solids From the Water

Applied Membranes melt-blown polypropylene sediment filters remove dirt, rust, sand, silt, and other suspended solids from the water to protect downstream plumbing, fixtures, and equipment from damage due to sediment buildup. The advanced graded pore structure maximizes the dirt-holding capacity and filter life by capturing the larger particles on the outside, and the smallest particles on the inside - so the entire depth of the filter is utilized. Applied Membranes 10-Micron filter cartridge is excellent for reverse osmosis pretreatment, whole-house water filtration, or as a stand-alone sediment control filtration solution. Designed to fit industry-standard 20" Big Blue (#20 BB) Filter Housings

Specifications Model: H-F20BB10CF Brand: Applied Membranes, Inc. Nominal Filtration Rating: 10 Micron Nominal Size: 20" Big Blue Actual Cartridge Dimensions: 4.5" OD x 1.125" ID x 20"L For Housing Dimensions: 7.5"OD x 22"L (Approx.) Changeout Differential Pressure: 35 psid (2.4 bar) recommended Max. Differential Pressure: 50 psid (3.4 bar) @ ambient 25 psid (1.7 bar) @ 140°F (60°C)

10 Micron Depth Filters Features

• 10 Micron Ultra-Fine Sediment Filtration - Filters particles as small as 0.0004" (1/5th the size of a human hair).
• Longest Life - Graded pores maximize dirt-holding capacity using the entire depth of the filter.
• Protect Appliances, Plumbing, Fixtures, and Equipment from damage due to sediment buildup & clogging.
• Universal Fit - Compatible with industry-standard 20" Big Blue (#20 BB) filter housings.
• Pure Polypropylene - Free of Surfactants, Binders, and Adhesives.
• FDA Listed Materials - All materials meet U.S. Food & Drug Administration requirements for food & beverage contact.
• Pharmaceutical Grade - Materials meet USP-XXIII Class VI Toxicity criteria. Safe for use in pharmaceutical applications.
