10" Sediment Water Filter | 5 Micron Filtration Rating | Melt-Blown Polypropylene Depth Filter

by AMI
SKU H-F1005CF
Availability:
In Stock for Immediate Shipment
Original price $3.75 - Original price $3.75
Original price
$3.75
$3.75 - $3.75
Current price $3.75

AMI Filters for RO System Water Filter Systems
5 Micron Sediment Filter for 10" Standard Housing
Removes Dirt, Rust, Sand, Silt, and Other Suspended Solids From the Water


Applied Membranes melt-blown polypropylene sediment filters remove dirt, rust, sand, silt, and other suspended solids from the water to protect downstream plumbing, fixtures, and equipments from damage due to sediment buildup. The advanced graded pore structure maximizes the dirt-holding capacity and filter life by capturing the larger particles on the outside, and the smallest particles on the inside - so the entire depth of the filter is utilized.

Commonly used as stage 1 in a home RO system, Applied Membranes 5-Micron filter cartridge is excellent for reverse osmosis pretreatment, or as a stand-alone sediment control filtration solution.


5 Micron Depth Filters Features

  • 5 Micron Filtration - Filters particles as small as 0.0002" (1/15th the size of a human hair).
  • Longest Life - Graded pores maximize dirt-holding capacity using the entire depth of the filter.
  • Protect Appliances, Plumbing, Fixtures, and Equipment from damage due to sediment buildup & clogging.
  • Universal Fit - Compatible with industry-standard 10" Standard (also known as SlimLine) filter housings.
  • Pure Polypropylene - Free of Surfactants, Binders, and Adhesives.
  • FDA Listed Materials - All materials meet U.S. Food & Drug Administration requirements for food & beverage contact.
  • Pharmaceutical Grade - Materials meet USP-XXIII Class VI Toxicity criteria. Safe for use in pharmaceutical applications.
  • Home RO Stage 1 - Standard Stage 1 Prefilter for most home RO systems

Filter Specifications

Model: H-F1005CF
Brand: Applied Membranes, Inc.
Nominal Filtration Rating: 5 Micron
Nominal Size: 10" Standard
Actual Cartridge Dimensions: 2.5" OD x 1.125" ID x 9.75"L
For Housing Dimensions: 4.5"OD x 11.4"L (Approx.)
Changeout Differential Pressure: 35 psid (2.4 bar) recommended
Max. Differential Pressure: 50 psid (3.4 bar) @ ambient
25 psid (1.7 bar) @ 140°F (60°C)
AMI Carbon Filter Water Filtration Specifications
AMI Carbon Filter Water Filtration Specifications

AMI 5 Micron Sediment Filters Are Compatible with most 10" Standrd Sediment Filters (Actual Length 9.75"), Including the Below

45331, 4137295, P5 ACE

Ace Hardware

DEV9109-08, P5

All Costguard Replacement Filters

WPD-110, W5P, 155014-52

American Plumber

P5, 155014, 155071, 155182

Ametek (Pentair)

1-SED10

APEC

SWS-10

Aqua Sun International

A1102, RV-SED5

Aquamaster

200621

AXEON Membranes

A-2137-1

Bruner

ED-S-1, ED-S-2, S5-10

Bunn

SED-S5

Campbell®

COR105, COR120, COR205, COR220

Cornelius

P5, P5-D

Culligan Water Filters

9320-1135, 9320-1150

EcoLab®

7156878

Ecowater

DEV9109-12

Everpure

200621

Flexeon

DEV9109-08, P5

Foodservice, Beverage, Coffee and Ice Filters

PX05-9 7/8, PX05-10

GE Water

MB-25098-05

Graver Technologies

200850

Hague®

RF-60

Honeywell

SDC-25-1005

Hydronix

738335

Ideal H2O™

IR-20

Instapure® / WaterPik®

SP-510

Keystone

SDF-25-1005

Liquatec

K-00069, K-00173

Manitowoc

S1016, A2112067

Marlo

MB-25098-05, GD-25-1005, SD-25-1005, FPMB5-978

Neo-Pure

101253

Nimbus

4712-87, 4621-41, 4715-87, 4621-14

Nu-Calgon

RS4

OmniFilter, Flotec

P5, 155014-43

Pentek (Pentair)

261-100, 33003051

PURA

261-100, 33003051

Pura UV Lamps & Filters

PFS205, PFS105

PureMark

PP-10-5, 03001

PurePro

R1111, FLTR-100

Pure-Tel

MB05-S

Purwater

12461, 9547, 9528, 9747, 13110, 17367

RainSoft

101-230

Selecto

SF31-SDS, 15-052-00, 15-052-03

Shurflo

SC-05

Sterilight

IF-SP-1005

TGI Pure, TopWay Global

1227867-V, VX05-9 7/8

Valuetrex

SF-4001

Vertex

47-1212419

Water Factory Systems/3M Purification

WHKF-DWH

Whirlpool

If you do not see your model listed or wish to learn more about compatibility, please contact us. Our certified water treatment experts will be happy to discuss your application. To ensure prompt and accurate information, please include as much information about your system as possible, such as: model, manufacturer, any available product manuals or literature associated with your system, and photographs of your system or filters.
