3" x 20" | RO Membrane to Replace Ametek 20 | 900 GPD | Applied Membranes, Incl

3" x 20" | RO Membrane to Replace Ametek 20 | 900 GPD | Applied Membranes, Incl

3" x 20" | RO Membrane to Replace Ametek 20 | 900 GPD | Applied Membranes, Incl

by AMI
SKU M-T3020A
Availability:
In Stock for Immediate Shipment
$193.19 - $193.19
$193.19
$193.19 - $193.19
$193.19


Applied Membranes 3x20 Commercial RO Membrane Replacement for Ametek 20

Applied Membranes M-T3020A 3x20 Commercial Reverse Osmosis Membrane element is specially designed to be a direct replacement for Ametek 20 Commercial RO membrane. AMI 3020 membrane produces 800 gallons per day (3028 liters per day) of purified water with 98% minimum salt rejection.

AMI Membranes are 100% Quality and Performance Tested in their ISO 9001:2015 Certified Facilities.

Applied Membranes Features:

  • High Rejection & Flow Rate
  • Manufactured in our ISO 9001:2015 Certified Facilities
  • 100% Performance and Quality Tested
  • Backed by our Experienced Technical Support Staff
  • High Quality for Consistent and Reliable Performance

Specifications for M-T3020A

AMI Model Number M-T3020A
Replaces: AMETEK 20
Size (Approximate): 3" Dia. x 20"L
Flow Rate: 800 gpd (3028 lpd)
Applied Pressure: 225 psi (15.5 bar)
Minimize Salt Rejection: 98%
Single Element Recovery: 10%
Exterior: Blue Tape
Membrane Type: Thin-Film Composite

Element Permeate flow may vary +/- 20%

Operating Limits for M-T3020A

Maximum Operating Temperature: 113°F (45°C)
Maximum Operating Pressure: 300 psig (20.7 bar)
Maximum Pressure Drop: 13 psig (0.9 bar)
Maximum Feed Flow Rate: 6 gpm (1.4m³/h)
pH Range, Continuous Operation: 2-11
pH Range, Short-Term Cleaning: 1-12
Maximum Feed Silt Density Index: SDI 4
Fere Clorine Tolerance: 0
