4x40 PVC Membrane Housing Pressure Vessel for RO Membranes

4x40 PVC Membrane Housing Pressure Vessel for RO Membranes

4x40 PVC Membrane Housing Pressure Vessel for RO Membranes

by AMI
SKU PV4040PWG
Availability:
In Stock for Immediate Shipment
$438.78 - $438.78
$438.78
$438.78 - $438.78
$438.78
AMI Components

4x40 PVC Membrane Housing Pressure Vessel for RO Membranes

AMI PVC pressure vessels for housing 4" x 40" membrane elements are ideal for lower pressure membrane applications up to 200 PSI and are designed for direct connection to AMI/Applied Membranes and FILMTEC/DOW style elements. The U-Pin style end closures are designed for ease of installing and replacing membrane elements, and the ½" FNPT connections for ease of connection with no special fittings required. Each membrane housing is individually inspected for quality assurance.

Each membrane housing is sold complete with End Plugs, U-Pins, Feed Plugs, and O-Rings. Mounting pads and straps are sold separately.

PVC Membrane Housing Specifications

AMI Part Number: PV4040PWG
For Membrane Size: 4" x 40"
For Membrane Type: AMI/Applied Membranes, DOW/FilmTec Style
Operating Pressure: 200 PSI (14 BAR) at 77°F (25°C) Maximum
Vessel Dimensions: 4" Dia. x 45" Length (10 cm Dia. x 114 cm Length)
Connections: ½" FNPT Feed, Brine, and Product
Configuration: End Entry
End Closures: U-Pin
Materials: NSF approved Rigid PVC, PVC end plugs, PVC reinforcement cuffs and stainless steel cuff bands

Warning: PVC pressure vessels are limited to a maximum pressure of 200 psi (14 BAR) at 77°F (25°C). Higher pressure, higher temperature or water hammer will lead to premature failure. It is highly recommended that when these conditions exist, a pressure switch or relief valve be installed to protect the vessel. Alternatively, you may consider a stainless steel or FRP vessel.

Replacement Components for PVC Housings

PV4040PD1212 End Plug with ½" Brine x ½" Product Ports, with O-Rings
PV-RR40U U-Pin
PV-OR40-342 O-Ring for End Plug – External
PV-OR40-210 O-Ring for End Plug – Internal
3850.005 ½" Plug for Permeate Port on Feed End
H-C111DC Lubricant for O-Rings, DOW Corning 111, 5 Oz
